• AUDI 0B5 DL501 Direct Shift Gearbox (DSG) 0B5927156B 0B5927156F 0B5927156E 0B5 DL501 7-Speed Transmission Control Unit TCU TCM Repair
1 1

AUDI 0B5 DL501 Direct Shift Gearbox (DSG) 0B5927156B 0B5927156F 0B5927156E 0B5 DL501 7-Speed Transmission Control Unit TCU TCM Repair

AUDI 0B5 DL501 Direct Shift Gearbox (DSG) 0B5927156B 0B5927156F 0B5927156E 0B5 DL501 7-Speed Transmission Control Unit TCU TCM Repair

$499.99 USD
$499.99 USD
Sale Sold out
Shipping calculated at checkout.

AUDI 0B5927156B 0B5927156F 0B5927156E 0B5 DL501 7Speed Control Unit TCU TCM
Repair Service

The buyer is required to send the part to us for a repair, along with fault codes. If fault codes are not received, there won't be any warranty or guarantees. To fix it properly, we must have the fault codes stored in the TCM.
Turnaround: 3-5 Business Days



0B5 927 413 / 0B5 927 413 A / 0B5 927 413 B / 0B5 927 807 / 0B5 927 807 A / 0B5 927 807 C / 0B5 927 807 D / 0B5398009 / 0B5398009A / 0B5398009B / 0B5398009C / 0B5398009D / 0B5398009E / 0B5398009F



Common Failure symptoms:

  • No reverse gear
  • No gears above 1st
  • Gears sticking
  • No gears at all
  • Limp home mode
  • Harsh gear change
  • Jerking / behaving erratically

Common fault codes:

  • P0726 – RPM Signal Of Engine Control Unit (Implausible Signal)
  • P173C – Valve 1 In Sub-gearbox 1 (Electrical Fault)
  • P173F – Valve 2 In Sub-gearbox 1 (Electrical Fault)
  • P1740 – Clutch Temperature Monitoring
  • P174A – Valve 3 In Sub-gearbox 1 (Electrical Fault)
  • P174B – Valve 4 In Sub-gearbox 1 (Electrical Fault)
  • P174C – Valve 1 In Sub-gearbox 2 (Electrical Fault)
  • P174C – Valve 2 In Sub-gearbox 2 (Electrical Fault)
  • P174E – Valve 3 In Sub-gearbox 2 (Electrical Fault)
  • P174F – Valve 4 In Sub-gearbox 2 (Electrical Fault)
  • P176A – Gear Actuator/Selector 1 (Not Adjustable)
  • P176A – Selector 1 Cannot Be Regulated
  • P176B – Selector 2 Cannot Be Regulated
  • P176B – Gear Actuator/Selector 2 (Not Adjustable)
  • P179C – Main Pressure Valve (Electrical Fault)
  • P179D – Cooling Oil Valve (Electrical Fault)
  • P17D4 – Valve 2 in Sub-gearbox 1 (Mechanical Malfunction)
  • P17D4 – Valve 3 In Sub-gearbox 1 (Mechanical Malfunction)
  • P17D5 – Valve 3 in Sub-gearbox 2 (Mechanical Malfunction)
  • P17D6 – Clutch 1 Pressure Too High
  • P17D7 – Clutch 2 Pressure Too High
  • P17D8 – Torque Limitation Due To Clutch Temperature
  • P17E0 – Gear Actuator 1 Mechanical Error
  • P17E0 – Gear Actuator/Selector 1 (Mechanical Error)

How to Get Your Unit Rebuilt

To initiate the process, please complete the form on our website (Submit a new order). Once you provide the necessary information, we will contact you via email with your mailing authorization number (ID) and shipping instructions to our facility.

Test and Repair

Each part undergoes thorough testing on our bench both before and after repair to ensure optimal functionality.

Turnaround

Most orders are completed within 24-48 hours, but complex repairs may take longer.

Warranty

We offer a 1-year warranty with unlimited mileage.

Programming & Coding

During the repair process, we do not alter the original programming and coding. When you receive your unit back, you can simply plug it in and start using your vehicle immediately.
